KIOXIA PM7-R 30.72TB Read Intensive SAS-4 SSD

Scale your cloud with the KIOXIA PM7-R 30.72TB SSD, built for massive storage needs!

KIOXIA /

1.92 TB 3.84 TB 7.68 TB 15.36 TB 30.72 TB

U.3

Base SIE SED

Product variants:

We won't be beaten on price. Request a quote.

Capacity

1.92 TB

3.84 TB

7.68 TB

15.36 TB

30.72 TB

Basic Specifications

Form Factor

2.5-inch (U.3, 15 mm Z-height)

Interface

SAS-4 (24G dual-port, backward compatible with 12G/6G/3G/1.5G)

Flash Memory Type

112-layer BiCS FLASH TLC 3D NAND

Endurance Rating

Read-Intensive – 1 DWPD (5 years)

Performance (Up To)

Sequential Read (128 KiB)

4,150 MB/s

4,200 MB/s

Sequential Write (128 KiB)

3,200 MB/s

3,400 MB/s

3,650 MB/s

4,100 MB/s

Random Read (4 KiB)

720K IOPS

Random Write (4 KiB)

80K IOPS

155K IOPS

160K IOPS

175K IOPS

Power Requirements

Power Loss Protection

Yes (Capacitor-based PLP)

Supply Voltage

5 V (+10% / -7%), 12 V (±10%)

Power Consumption (Ready)

5 W (typical)

Reliability / Endurance

DWPD (5-year)

1.0

MTTF

2,500,000 hours

Warranty

5 years

Dimensions

Form Factor

2.5-inch (U.3)

Height

15.0 mm (+0 / -0.5 mm)

Width

69.85 mm (±0.25 mm)

Length

100.45 mm (Max)

Weight

150 g (Max)

Environmental

Temperature (Operating)

0 °C to 70 °C

Humidity (Operating)

5% to 95% R.H.

Vibration (Operating)

21.27 m/s² (2.17 G, 5–800 Hz)

Shock (Operating)

9.8 km/s² (1,000 G, 0.5 ms)

Security & Management

SIE Option

Sanitize Instant Erase (Crypto Erase)

SED Option

TCG Opal & Ruby SSC

SED FIPS Option

FIPS 140-2 / 140-3 Level 2 compliant

Encryption

AES-256 hardware encryption

More Information

Maximise enterprise performance with the KIOXIA PM7-R Series Enterprise SAS SSD, designed for read-intensive workloads in large-scale data centres. Available in capacities from 1.92 TB to 30.72 TB, the PM7-R Series delivers exceptional reliability, scalability, and endurance for modern cloud and enterprise storage environments.

Powered by the 24 G SAS-4 interface and advanced 112-layer BiCS FLASH‚Ñ¢ TLC NAND, these 15 mm 2.5‚ drives achieve up to 4,200 MB/s sequential read and 4,100 MB/s sequential write speeds, with 1 DWPD endurance and integrated Power Loss Protection (PLP). Engineered for sustained reliability, the PM7-R Series ensures stable throughput under continuous enterprise workloads.

Ideal for cloud deployments, data warehousing, streaming media, and web server environments, the PM7-R Series provides comprehensive data protection with Base, SIE (Sanitise Instant Erase), SED, and FIPS SED security options. Combining high capacity, efficiency, and proven SAS dependability, it is the optimal read-intensive storage solution for mission-critical data centres.
