KIOXIA RM7-R 7.68TB Value SAS SSD (SIE)

Optimise your storage with the KIOXIA RM7-R 7.68TB SSD, perfect for value storage!

KIOXIA /

0.96 TB 1.92 TB 3.84 TB 7.68 TB

U.2

SIE SED

Product variants:

We won't be beaten on price. Request a quote.

Capacity

0.96 TB

1.92 TB

3.84 TB

7.68 TB

Basic Specifications

Form Factor

U.2 15mm (2.5-inch)

Interface

SAS-3 (12 Gbit/s)

Flash Memory Type

BiCS FLASH TLC 3D NAND

Endurance Rating

Standard - 1 DWPD

Performance (Up To)

Sequential Read

1,100 MB/s

Sequential Write

850 MB/s

1,050 MB/s

Random Read (4K)

180K IOPS

190K IOPS

Random Write (4K)

40K IOPS

Power Requirements

Power Loss Protection

Yes

Idle Power

3.6 W

Reliability / Endurance

DWPD (5-year)

1.0

DWPD (3-year)

1.66

Total Bytes Written (5-year)

1.75 PBW

3.5 PBW

7.0 PBW

14.0 PBW

Warranty

5 years

MTBF

2,500,000 hours

Dimensions

Form Factor

U.3 (2.5-inch)

Thickness

15 mm

Environmental

Temperature (Operating)

0 °C to 70 °C

Temperature (Non-operating)

-40 °C to 80 °C

Security & Management

Encryption

SED option (TCG Enterprise SSC), SIE option

More Information

Upgrade your enterprise storage with the KIOXIA RM7-R Series Value SAS SSD, engineered for high-capacity, read-intensive applications across modern data centres. Available in capacities from 0.96 TB to 7.68 TB, the RM7-R Series delivers exceptional performance and reliability while maintaining compatibility with existing SAS-based infrastructures, making it an ideal replacement for traditional SATA drives.

Powered by BiCS FLASH‚Ñ¢ TLC NAND technology and the SAS-3 interface, these 2.5" Value SAS drives achieve up to 1,100 MB/s sequential read and 1,050 MB/s sequential write speeds with up to 190 K IOPS random read performance. With 1 DWPD endurance and integrated Power Loss Protection (PLP), the RM7-R Series ensures consistent reliability for mission-critical, read-intensive workloads.

Designed for content delivery networks, streaming media platforms, data warehousing, and web servers, the RM7-R Series provides enhanced reliability with SIE (Sanitize Instant Erase) security for safe data management. Combining enterprise endurance with value efficiency, it delivers an optimal balance of performance, capacity, and affordability for next-generation data centre storage.
