KIOXIA RM7-V 3.84TB Mixed Use Value SAS SSD (SIE)

Strengthen your storage with the KIOXIA RM7-V 3.84TB SSD, perfect for mixed-use value storage!

KIOXIA /

0.96 TB 1.92 TB 3.84 TB

U.2

SIE SED

Product variants:

We won't be beaten on price. Request a quote.

Capacity

3.84 TB

1.92 TB

0.96 TB

Basic Specifications

Form Factor

U.2 (2.5-inch), 15mm thickness

Interface

SAS-3

Interface Speed

12.0 Gbit/s, 6.0 Gbit/s, 3.0 Gbit/s, 1.5 Gbit/s

Flash Memory Type

BiCS FLASH™ TLC

Performance

Sustained 128 KiB Sequential Read

1,100 MB/s

Sustained 128 KiB Sequential Write

1,050 MB/s

850 MB/s

Sustained 4 KiB Random Read

190K IOPS

180K IOPS

Sustained 4 KiB Random Write

65K IOPS

40K IOPS

Power Requirements

Supply Voltage

12 V ± 10 %, 5 V +10 % / -7 %

Power Consumption (Ready)

3.6 W typ.

Reliability

MTTF

2,500,000 hours

Warranty

5 years

DWPD

Dimensions

Thickness

15.0 mm +0 / -0.5 mm

Width

69.85 mm ± 0.25 mm

Length

100.45 mm Max

Weight

130 g Max

Environmental

Temperature (Operating)

0 °C to 70 °C

Temperature (Non-operating)

-40 °C to 80 °C

Humidity (Operating)

5 % to 95 % R.H.

Vibration (Operating)

21.27 m/s² { 2.17 Grms } ( 5 to 800 Hz )

Shock (Operating)

9.8 km/s² { 1,000 G } ( 0.5 ms )

More Information

Strengthen your enterprise storage with the KIOXIA RM7-V Series Value SAS SSD, engineered to deliver exceptional reliability and efficiency for mixed-use data centre workloads. Available in capacities from 0.96TB to 3.84TB, the RM7-V Series is designed as a powerful upgrade for existing SATA infrastructures, offering improved performance and endurance while maintaining seamless compatibility with current server systems.

Powered by BiCS FLASH NAND technology, and the SAS-3 interface, these 2.5" Value SAS drives achieve up to 1,100 MB/s sequential read and 1,050 MB/s sequential write speeds, with up to 190K IOPS random read performance. Featuring 3 DWPD endurance and integrated Power Loss Protection (PLP), the RM7-V Series ensures consistent reliability across demanding enterprise environments.

Ideal for virtualised infrastructures, database operations, streaming media servers, and content management systems, the RM7-V Series combines enterprise-grade security with SIE (Sanitise Instant Erase) features for data protection. Designed to extend the life of existing SAS-based deployments, it delivers a cost-effective, high-performance foundation for modern data centres.
